Cantilever rack - single-sided corbel base KJZ301080
Code: KJZ301080
Medium load rack for standing and lying long material, height 3000, width 1000, depth 800 mm, number of arms 5 per post, arm load full description and parameters
Description and technical parameters
Cantilever rack - single-sided corbel base KJZ301080
Medium load rack for standing and lying long material, height 3000, width 1000, depth 800 mm, number of arms 5 per post, arm load capacity 250 kg, one-sided web load capacity 1250 kg. Color RAL 5010 blue. For these products, even with a purchase value over CZK 3,000 excluding VAT, shipping is paid according to the place of delivery. Personal collection in Chrudim.
- for storage of board and board material
- cylindrical profiles IPE 140
- height-adjustable arms in 100 mm increments
- perfect security worked out to the last detail
- production is approved by SZU and is produced under ISO 9001 management conditions
- the consoles can be supplemented with grates (hot-dip galvanized) or chipboards (raw DTD)
- upon request, it is possible to supply racks in a different size (columns up to a maximum height of 10 m, consoles up to a maximum length of 2 m), with a different load capacity or in an outdoor hot-dip galvanized version
| Total height: | 3000 mm |
|---|---|
| Width: | 1000 mm |
| Depth: | 800 mm |
| The bearing capacity of the web is one-sided: | 1250 kg |
| Carrying capacity of the arm: | 250 kg |
| Number of arms: | 5 |
| Warranty (years): | 5 |
| Manufacturer: |
|
All models
| Code | KJZ201050 | KJZ201080 | KJZ251050 | KJZ251080 | KJZ301050 | Currently browsing KJZ301080 | KJZ201350 | KJZ201380 | KJZ251350 | KJZ251380 | KJZ301350 | KJZ301380 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Total height | 2000 mm | 2000 mm | 2500 mm | 2500 mm | 3000 mm | 3000 mm | 2000 mm | 2000 mm | 2500 mm | 2500 mm | 3000 mm | 3000 mm |
| Width | 1000 mm | 1000 mm | 1000 mm | 1000 mm | 1000 mm | 1000 mm | 1300 mm | 1300 mm | 1300 mm | 1300 mm | 1300 mm | 1300 mm |
| Depth | 500 mm | 800 mm | 500 mm | 800 mm | 500 mm | 800 mm | 500 mm | 800 mm | 500 mm | 800 mm | 500 mm | 800 mm |
| The bearing capacity of the web is one-sided | 2340 kg | 1650 kg | 2200 kg | 1500 kg | 2000 kg | 1250 kg | 2340 kg | 1650 kg | 2200 kg | 1500 kg | 2000 kg | 1250 kg |
| Carrying capacity of the arm | 430 kg | 250 kg | 430 kg | 250 kg | 430 kg | 250 kg | 430 kg | 250 kg | 430 kg | 250 kg | 430 kg | 250 kg |
| Number of arms | 4 | 4 | 4 | 4 | 5 | 5 | 4 | 4 | 4 | 4 | 5 | 5 |
| In stock | No | No | No | No | No | No | No | No | No | No | No | No |
| Price without VAT | 809.63 Eur | 823.59 Eur | 935.27 Eur | 935.27 Eur | 1 046.94 Eur | 1 158.61 Eur | 823.59 Eur | 830.57 Eur | 921.31 Eur | 921.31 Eur | 1 074.86 Eur | 1 186.53 Eur |
