Leveling screw
Code: K-1209E-M8
In stock
Fasteners for aluminium profiles – T-slot nuts, T-head screws, leveling feet
Fasteners for aluminium profiles include T-slot nuts and spring nuts with M5–M8 threads, slot screws with T-head, half-round, cylindrical or countersunk heads, right-angle connectors, clamps, hinges and M8 leveling screws with ±50 mm height adjustment. They are used to assemble frames, tables and guards from the aluminium profile system, and the vast majority of items are in stock.
more
Adjustable Foot AD-5508MRM
Code: AD-5508MRM
In stock
Perpendicular coupling KCH1-30
Code: KCH1-30
In stock
T-head screw KDA-6x12
Code: KDA-6*12
In stock
Steel hinge for 40 x 40 profile
Code: PANT
M10 fastener for 40x40 aluminum profile
Code: CONNECTOR M10(40x40 item)
In stock
Half round head screw KDB-6x16
Code: KDB-6*16
Connecting screw 05.01083.00
Code: 05.01083.00
In stock
T-head screw KDA-8x20
Code: KDA-8*20
In stock
T-head screw TB10-45-0820
Code: TB10-45-0820
In stock
T-head screw KDA-8x16
Code: KDA-8*16
In stock
T-head screw TB10-40-0816
Code: TB10-40-0816
In stock
Half round head screw KDB-8x16
Code: KDB-8*16
Screw with cylindrical head KDC-6x10
Code: KDC-6*10
In stock
Screw with cylindrical head KDC-8x12
Code: KDC-8*12
T-slot nut KEA-30
Code: KEA-30
In stock
T-slot nuts and slot screws for the aluminium profile system
Fasteners for aluminium profiles are the screws, nuts and connecting elements used to join slotted profiles into frames, tables, racks and machine guards. T-slot nuts have M5–M8 threads and weigh from 3 g, T-head screws are 12–20 mm long and a leveling screw lets you adjust the height by ±50 mm. The range matches aluminium profiles, most commonly sized 30 × 30 to 45 × 90 mm with an 8 or 10 mm slot.
Which T-slot nuts and slot screws should you choose?
T-slot nuts are inserted into the profile slot and hold the screw of the attached part. The T-slot nut KEA-30 has an M6 thread; the 096H series nuts are available with M5, M6 and M8 threads at 3 g each. Spring nuts KEE-30 (M6, 8.7 g) and KEE-40 (M8, 10.2 g) complete the range for mounting into an already assembled frame. T-head slot screws such as the T-head screw KDA-8x16 (16 mm, 10 g) come in lengths of 12–20 mm; half-round, cylindrical and countersunk head screws in M6 and M8 are also available.
Connectors, clamps and feet for slotted aluminium profiles
Two profiles are joined with the right-angle connectors KCH1-30 and KCH1-40 (20 g), the KCR1-40 clamp made of nickel-plated zinc alloy, the M10 connecting element for 40 × 40 profiles and the M12 × 30 connecting screw for 40 × 40 and 45 × 45 profiles. Further types are available among the joints for aluminium profiles. The structure stands on the leveling screw K-1209E-M8 with a Ø 38 mm base and 87 mm height or on the AD-5508MRM adjustable foot (M8, 55 mm); guard doors are carried by the steel hinge for 40 × 40 profiles.
| Type | Thread / size | Parameters | Example model |
|---|---|---|---|
| T-slot nuts | M5, M6, M8 | weight 3 g | KEA-30, 096H10830 |
| Spring nuts | M6, M8 | 8.7–10.2 g | KEE-30, KEE-40 |
| T-head screws | length 12–20 mm | 6.2–10 g | KDA-8x16, TB10-45-0820 |
| Half-round, cylindrical and countersunk head screws | M6, M8 | length 15.3–20.4 mm | KDB-6x12, KDD-8x16 |
| Profile connectors and clamps | M10, M12 × 30 | for 40 × 40 and 45 × 45 profiles | KCH1-40, KCR1-40 |
| Leveling screws and feet | M8 | ±50 mm, Ø 38 mm base | K-1209E-M8, AD-5508MRM |
| Hinge | 40 × 40 profile | steel, black | PANT |
Do you need a bill of materials for the fasteners of your structure? Send us a sketch with dimensions – Enprag designers prepare a 3D design free of charge and supply the material by the piece, cut with a drawing or as a finished assembly. Contact Enprag.
Frequently asked questions
What fasteners do I need for aluminium profiles?
The basis is a T-slot nut in the slot and the screw of the attached part – Enprag offers M5–M8 nuts and T-head screws 12–20 mm long. To join two profiles, choose a right-angle connector or a clamp, for example KCH1-40.
Are Enprag fasteners compatible with item or Bosch Rexroth profiles?
Enprag aluminium profiles with 8 and 10 mm slots are compatible with item, Bosch Rexroth, Haberkorn and Alutec systems; the M10 connecting element is designed for item profiles 40 × 40. Enprag designers verify the specific combination for your profile.
How do I level an aluminium profile structure on an uneven floor?
Use the Enprag leveling screw K-1209E-M8 with an M8 thread, a ±50 mm adjustment range and a Ø 38 mm base. A shorter alternative is the AD-5508MRM adjustable foot, 55 mm long.
Which slot screws does Enprag offer?
Enprag offers T-head screws in lengths of 12–20 mm and half-round, cylindrical or countersunk head screws with M6 and M8 threads. Most types are in stock with delivery within a few days.
